buy antidepressant buy amitriptyline lav dosis naltrexon naltrexon nerve pain amitriptyline nerve pain amitriptyline lav ldn jensen.azurewebsites.net dosis koop abortuspil abortuspil kopen williamgonzalez.me abortuspil online bestellen abortion pill usa legal abortion pill kit link buy abortion pill online usa 범례 한 아이템의 클릭 이벤트를 잡아서 시리즈를 Visible 효과를 주는 샘플입니다.



C#


using System;
using System.Collections.Generic;
using System.ComponentModel;
using System.Data;
using System.Drawing;
using System.Text;
using System.Windows.Forms;
using Hippo;

namespace WindowsApplication1
{
public partial class Form1 : Form
{
public Form1()
{
InitializeComponent();
}

private void Form1_Load(object sender, EventArgs e)
{
SeriesList sList = new SeriesList();
sList.ChartType = ChartType.Line;

Random r = new Random();
for(int i = 0; i < 5; i++)
{
Series sr = new Series();

for(int x = 0; x < 5; x++)
{
SeriesItem item = new SeriesItem();
item.Name = x.ToString();
item.YValue = r.Next(90);

sr.items.Add(item);
}
sList.SeriesCollection.Add(sr);
}

this.hHippoChart1.SeriesListDictionary.Add(sList);
this.hHippoChart1.DrawChart();
}

private void hHippoChart1_ChartMouseClick(object sender, MouseEventArgs e)
{
if (e.Button == MouseButtons.Left)
{
for(int i = 0; i < this.hHippoChart1.LegendBox.LegendBoxItems[0].Rows.Count; i++)
{
LegendRow row = this.hHippoChart1.LegendBox.LegendBoxItems[0].Rows[i];
RectangleF rowRec = row.ItemRectangle;
if (e.X >= rowRec.Left && e.X <= rowRec.Right && e.Y >= rowRec.Top && e.Y <= rowRec.Bottom)
{
if (this.hHippoChart1.SeriesListDictionary[0].SeriesCollection[i].ForeColor == Color.Black)
{
this.hHippoChart1.SeriesListDictionary[0].SeriesCollection[i].ForeColor = Color.Red;
for(int x = 0; x < this.hHippoChart1.SeriesListDictionary[0].SeriesCollection.Count; x++)
{
if (x != i) this.hHippoChart1.SeriesListDictionary[0].SeriesCollection[x].Visible = false;
}
}
else
{
this.hHippoChart1.SeriesListDictionary[0].SeriesCollection[i].ForeColor = Color.Black;
for(int x = 0; x < this.hHippoChart1.SeriesListDictionary[0].SeriesCollection.Count; x++)
{
if (x != i) this.hHippoChart1.SeriesListDictionary[0].SeriesCollection[x].Visible = true;
}
}
}
}
this.hHippoChart1.DrawChart();
}
}
}
}

VB


Imports System.Collections.Generic
Imports System.ComponentModel
Imports System.Data
Imports System.Drawing
Imports System.Text
Imports System.Windows.Forms
Imports Hippo

Namespace WindowsApplication1
Public Partial Class Form1
Inherits Form
Public Sub New()
InitializeComponent()
End Sub

Private Sub Form1_Load(sender As Object, e As EventArgs)
Dim sList As New. SeriesList()
sList.ChartType = ChartType.Line

Dim r As New. Random()
For i As Integer = 0 To 4
Dim sr As New. Series()

For x As Integer = 0 To 4
Dim item As New. SeriesItem()
item.Name = x.ToString()
item.YValue = r.[Next](90)

sr.items.Add(item)
Next
sList.SeriesCollection.Add(sr)
Next

Me.hHippoChart1.SeriesListDictionary.Add(sList)
Me.hHippoChart1.DrawChart()
End Sub

Private Sub hHippoChart1_ChartMouseClick(sender As Object, e As MouseEventArgs)
If e.Button = MouseButtons.Left Then
For i As Integer = 0 To Me.hHippoChart1.LegendBox.LegendBoxItems(0).Rows.Count - 1
Dim row As LegendRow = Me.hHippoChart1.LegendBox.LegendBoxItems(0).Rows(i)
Dim rowRec As RectangleF = row.ItemRectangle
If e.X >= rowRec.Left AndAlso e.X <= rowRec.Right AndAlso e.Y >= rowRec.Top AndAlso e.Y <= rowRec.Bottom Then
If Me.hHippoChart1.SeriesListDictionary(0).SeriesCollection(i).ForeColor = Color.Black Then
Me.hHippoChart1.SeriesListDictionary(0).SeriesCollection(i).ForeColor = Color.Red
For x As Integer = 0 To Me.hHippoChart1.SeriesListDictionary(0).SeriesCollection.Count - 1
If x <> i Then
Me.hHippoChart1.SeriesListDictionary(0).SeriesCollection(x).Visible = False
End If
Next
Else
Me.hHippoChart1.SeriesListDictionary(0).SeriesCollection(i).ForeColor = Color.Black
For x As Integer = 0 To Me.hHippoChart1.SeriesListDictionary(0).SeriesCollection.Count - 1
If x <> i Then
Me.hHippoChart1.SeriesListDictionary(0).SeriesCollection(x).Visible = True
End If
Next
End If
End If
Next
Me.hHippoChart1.DrawChart()
End If
End Sub
End Class
End Namespace
